Acura EL ES [2001 .. 2005]1.7
- Generation: ES [2001 .. 2005] [USDM]
- Production: [2001 .. 2005]
- Sales regions: USA+, Canada
- Power: 127 hp | 95 kW | 129 PS
- Engine: 1.7 L, D17A2, I4 , Petrol
- Center Bore / Hub Bore: 56.1 mm
- Bolt Pattern (PCD): 4×100
- Wheel Fasteners: Lug nuts
- Thread Size: M12 x 1.5
- Wheel Tightening Torque: 108 Nm
| Tire | Rim | Offset Rangemm |  bar |
|---|---|---|---|
| OE195/60R15 87H | 6Jx15 ET45 | 43 – 47 | 2.1 |
| 195/55R16 87H | 6Jx16 ET45 | 43 – 47 | 2.1 |
| 205/50R16 87H | 6.5Jx16 ET45 | 43 – 47 | 2.1 |
| 205/45R17 88V | 6.5Jx17 ET45 | 43 – 47 | 2.3 |
| 215/45R17 91V | 7Jx17 ET42 | 43 – 47 | 2.3 |
Acura EL MB [1997 .. 2000]1.6i
- Generation: MB [1997 .. 2000] [USDM]
- Production: [1997 .. 2000]
- Sales regions: USA+, Canada
- Power: 127 hp | 95 kW | 129 PS
- Engine: 1.6 L, D16Y8, I4 , Petrol
- Center Bore / Hub Bore: 56.1 mm
- Bolt Pattern (PCD): 4×100
- Wheel Fasteners: Lug nuts
- Thread Size: M12 x 1.5
- Wheel Tightening Torque: 108 Nm
| Tire | Rim | Offset Rangemm | bar |
|---|---|---|---|
| OE195/55R15 84V | 6Jx15 ET45 | 43 – 47 | 2.1 |
| 195/50R16 84V | 6Jx16 ET45 | 43 – 47 | 2.1 |
| 195/50R16 84V | 6.5Jx16 ET45 | 43 – 47 | 2.1 |
| 205/50R16 87V | 6.5Jx16 ET45 | 43 – 47 | 2.1 |
| 205/45R16 83V | 7Jx16 ET42 | 43 – 47 | 2.3 |
