Acura ILX DE Facelift [2019 .. 2022]2.4i
- Generation: DE Facelift [2019 .. 2022] [USDM]
- Production: [2019 .. 2022]
- Sales regions: USA+, Canada
- Power: 201 hp | 150 kW | 204 PS
- Engine: 2.4 L, K24V7, I4 , Petrol
- Trim Levels: Standard, Premium, Technology, A-Spec
- Center Bore / Hub Bore: 64.1 mm
- Bolt Pattern (PCD): 5×114.3 (5×4.5)
- Wheel Fasteners: Lug nuts
- Thread Size: M12 x 1.5
- Wheel Tightening Torque: 108 Nm
| Tire | Rim | Offset Rangemm | |
|---|---|---|---|
| OE215/45R17 87V | 7Jx17 ET50 | 48 – 52 | 2.3 |
| 225/40R18 89V | 7.5Jx18 ET50 | 48 – 52 | 2.3 |
| 245/35ZR18 89W | 8Jx18 ET45 | 48 – 52 | 2.5 |
Acura ILX DE Facelift [2016 .. 2018]2.4i
- Generation: DE Facelift [2016 .. 2018] [USDM]
- Production: [2016 .. 2018]
- Sales regions: USA+
- Power: 201 hp | 150 kW | 204 PS
- Engine: K24V7, I4 , Petrol
- Center Bore / Hub Bore: 64.1 mm
- Bolt Pattern (PCD): 5×114.3 (5×4.5)
- Wheel Fasteners: Lug nuts
- Thread Size: M12 x 1.5
- Wheel Tightening Torque: 108 Nm
| Tire | Rim | Offset Rangemm | |
|---|---|---|---|
| OE215/45R17 87V | 7Jx17 ET50 | 48 – 52 | 2.3 |
| 225/40R18 89V | 7.5Jx18 ET50 | 48 – 52 | 2.3 |
| 245/35ZR18 89W | 8Jx18 ET45 | 48 – 52 | 2.5 |
Acura ILX DE [2012 .. 2015]1.5H
- Generation: DE [2012 .. 2015] [USDM]
- Production: [2012 .. 2015]
- Sales regions: USA+
- Power: 111 hp | 83 kW | 113 PS
- Engine: LDA/LEA15, I4 , Hybrid
- Center Bore / Hub Bore: 64.1 mm
- Bolt Pattern (PCD): 5×114.3 (5×4.5)
- Wheel Fasteners: Lug nuts
- Thread Size: M12 x 1.5
- Wheel Tightening Torque: 108 Nm
| Tire | Rim | Offset Rangemm | |
|---|---|---|---|
| OE205/55R16 89H | 6.5Jx16 ET45 | 43 – 47 | 2.1 |
| 205/50R17 89H | 6.5Jx17 ET45 | 43 – 47 | 2.1 |
| 205/45R18 87V | 7Jx18 ET45 | 43 – 47 | 2.3 |
