Honda Accord Bolt Pattern, Rim Size, Hub Bore, Offsets And Tire Size

Honda Acord Wheel Fitment By Generations

Honda Accord 1st Generation (1976-1981) Wheel Fitment

For the 1st generation of the Honda Accord, which ran from 1976 to 1981, the wheel specifications are as follows: The hub bore was consistently 67.1mm across all years, and the wheel width remained at 5.5 inches. The wheel diameter varied from 13 inches in 1976 and 1977, to 14 inches in 1978 and 1979, and 15 inches in 1980 and 1981. The tire sizes changed accordingly, from 175/70R13 in the early years to 195/60R15 by the end of the generation. The bolt pattern stayed the same at 4×120, with offset ranging from +43mm in the 1976–1979 models to +47mm in the 1981 model.

Honda Accord 2nd Generation (1981–1985) Fitment

In the 2nd generation (1981–1985), the hub bore was reduced to 56.1mm, and the wheel width increased slightly to 5.5 inches in 1981 and 1982, before increasing to 6.0 inches in 1983 and remaining that size through 1985. The wheel diameter began at 13 inches in 1981 and 1982, then moved to 14 inches in 1983 and 1984, and ended with 15 inches in 1985. Tire sizes also grew, starting from 175/70R13 and moving up to 195/60R15. The bolt pattern remained 4×120, and the offset increased from +43mm in 1981 and 1982, to +45mm in 1983 and 1984, and finally +47mm in 1985.

Honda Accord 3rd Generation (1985–1989) Fitment

For the 3rd generation (1985–1989), the hub bore size stayed at 56.1mm, but the wheel width varied from 5.5 inches in 1985 and 1986 to 6.0 inches in 1987 and 1988, and finally 6.5 inches in 1989. The wheel diameter started at 13 inches in 1985 and 1986, moved to 14 inches in 1987 and 1988, and then reached 15 inches in 1989. Tire sizes followed suit, growing from 175/70R13 to 195/60R15. The bolt pattern shifted from 4×120 to 4×100 starting in 1985, and the offset remained steady at +43mm in the earlier years, increasing slightly to +45mm in 1987, and then to +47mm in 1989.

Honda Accord 4th Generation (1989–1993) Fitment

For the 4th generation (1989–1993), the hub bore increased slightly to 64.1mm. The wheel width started at 6.0 inches in 1989 and 1990, then expanded to 6.5 inches in 1991–1993. The wheel diameter started at 14 inches and remained so through 1990, before shifting to 15 inches in 1991–1993. Tire sizes ranged from 185/70R14 to 195/60R15. The bolt pattern changed to 5×114.3, and the offset steadily increased from +48mm in 1989 to +52mm by 1993, offering a wider range of wheel options throughout the generation.

Honda Accord 5th Generation (1994–1997) Fitment

The 5th generation (1994–1997) saw a hub bore of 64.1mm with a consistent wheel width of 6.0 inches for 1994 and 1995, and 6.5 inches for 1996 and 1997. The wheel diameter increased from 15 inches to 16 inches by 1996, with tire sizes also growing from 195/60R15 to 205/55R16. The bolt pattern was set at 5×114.3, with offset starting at +48mm and increasing to +50mm and +52mm by the end of the generation.

Honda Accord 6th Generation (1998–2002) Fitment

For the 6th generation (1998–2002), the hub bore remained at 64.1mm, but wheel widths increased. The early years (1998–1999) featured 6.0-inch wide wheels, while later years moved to 6.5 inches in 2000 and 2001, and finally 7.0 inches in 2002. Wheel diameters also grew, starting from 15 inches and reaching 17 inches by 2002. The bolt pattern was consistently 5×114.3, with offsets increasing from +58mm in 1998–1999 to +60mm in 2000–2001, and finally +62mm in 2002.

Honda Accord 7th Generation (2003–2007) Fitment

The 7th generation (2003–2007) kept the hub bore at 64.1mm, with wheel widths ranging from 6.5 inches in 2003 to 7.5 inches in 2007. The wheel diameter started at 15 inches in 2003, grew to 16 inches in 2004–2005, and ended with 18 inches in 2007. Tire sizes ranged from 195/65R15 to 225/45R18. The bolt pattern remained 5×114.3, with offsets fluctuating between +53mm in 2003 and 2007, and increasing to +55mm in 2006 and +57mm in 2005.

Honda Accord 8th Generation (2008–2012) Fitment

The 8th generation (2008–2012) maintained a hub bore of 64.1mm. Wheel widths varied from 7.0 inches in 2008 to 8.0 inches in 2012, and wheel diameters increased from 16 inches in 2008 to 19 inches by 2012. Tire sizes started at 205/60R16 and grew to 235/40R19. The bolt pattern was consistently 5×114.3, with offsets ranging from +53mm to +57mm across the years.

Honda Accord 9th Generation (2013–2017) Fitment

For the 9th generation (2013–2017), the hub bore stayed at 64.1mm. Wheel widths ranged from 7.0 inches in 2013 to 7.5 inches in 2014–2017, with diameters ranging from 16 inches to 18 inches. Tire sizes varied from 205/60R16 to 225/50R18. The bolt pattern remained 5×114.3, with offsets ranging from +53mm to +57mm throughout the generation.

Honda Accord 10th Generation (2018–2022) Fitment

The 10th generation (2018–2022) kept the same hub bore size of 64.1mm. Wheel widths varied from 7.5 inches in 2018 to 8.5 inches in 2020–2022, with diameters ranging from 17 inches to 19 inches. Tire sizes moved from 225/50R17 to 235/40R19. The bolt pattern stayed 5×114.3, with offsets ranging from +53mm in 2018 to +57mm in 2020–2022.

Honda Accord 11th Generation (2023–Present) Fitment

For the latest 11th generation (2023–present), the hub bore remains at 64.1mm. Wheel widths vary from 7.5 inches in 2023 to 8.5 inches in 2024–2025. Diameters are 17 inches to 19 inches, with tire sizes ranging from 225/50R17 to 235/40R19. The bolt pattern is still 5×114.3, and the offset has slightly increased from +53mm in 2023 to +57mm in 2025.
